1. On both ends of the low end of the high output, large amount of oil;
2. Low pressure use high pressure gear pump, stability and reliability;
3. Dual active, electromagnetic wired remote control , can solve the problem of large tonnage, long type hydraulic cylinder which reset too slow
4. Pressure overload protection device, avoid overpressure and damage the equipment;
5. Dual active, use three-potential four-way valve, can be forward, maintain, back, maintain the pressure of these two oil circuits, keep the cylinder staying.
|
Item No.
|
DHB300-D2B
|
|
Working pressure
|
high pressure£º70Mpa
|
low pressure£º10Mpa
|
|
Rated output
|
high£º0.9L/min
|
low£º5L/min
|
|
Power Rating
|
0.75Kw
|
Speed
|
1400r/min
|
|
Working Power
|
AC220V/50Hz £¨customizable£©
|
|
Oil Capacity
|
7L£¨customizable£©
|
Type of oil
|
15#-46#
antiwear hydraulic oil
|
|
