1.Design to accommodate hexagonal dies for applying compression lugs to copper, aluminum conductors.
2.Two stage pumping action for rapid ram advance to the connector hold positon with minimum pumping action.
3.Manual retraction when the max pressure reached by twisting the handle.
4.The glass fiber operation insulates the stick, can bear the electric voltage 200KV, keeping on the minute.
5.180¡ã rotatable head.
6.The pressure outside the body adjusts to press the valve, don¡¯t need the whole structure to lie down.
|
Item No.
|
CPO-400
|
|
Crimping Range
|
50-400mm2
|
|
Crimping Force
|
130KN
|
|
Crimping Type
|
hexagon crimping
|
|
Stroke
|
22mm
|
|
Length
|
approx.630mm
|
|
Weight
|
approx.6.6kg
|
|
Package
|
Plastic case
|
|
Accessories
|
Crimping dies: 50,70,95,120,,150,185,240,300,400mm2
|
|
