Specification
|
Cutting,punching,horzontal bending,erective bending
|
|
Input voltage/control voltage
|
Single phase 50Hz,220v
|
|
Rating working oil pressure
|
700kgf/cm2 (over pressure safety valve setting valeue)
|
|
Dimension of moveable workbench
|
890mm(L)x670mm(W)x940mm(H)
|
|
Busbar cutting capability
|
(Copper busbar/aluminum busbar)200*12mm
|
|
Outlet force of busbar cutter
|
20Ton
|
|
Cutting Range
|
200mm(Width)X12mm(Thickness)
|
|
Outlet force of puncher
|
35Ton
|
|
The distance between hole centre busbar edge
|
70mm
|
|
Distancefrom hole to sheet side
|
110mm
|
|
Punching capability- copper busbar/ aluminum busbar
|
¦µ6-¦µ20.5£¨Max.Thickness):13mm
|
|
Standard assembled punching dies
|
3/8"(¦µ10.5m©O),1/2"(¦µ13.8m©O),5/8"(¦µ17m©O),3/4"(¦µ20.5m©O)
|
|
Outlet force of bender
|
25Ton
|
|
Horizontal bending capability
|
copper bus bar ¡Ü125*10, aluminium busbar 125*12.5
|
|
Embossing capability
|
900KN
|
|
Embossing stroke
|
30mm
|
|
Embossing range
|
copper/ aluminium busbar ¡Ü150*15mm
|
